Характеристики
80мм 25Вт редукторный микро-активный мотор однофазный 50Гц соотношение 18:1 более низкая цена замена Spg S8125GXCE/S8KA18B.
История изменения цены
*Текущая стоимость 5354.9 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Sep-18-2025 | 6371.84 руб. | 6690.41 руб. | 6530.5 руб. |
| Aug-18-2025 | 6318.39 руб. | 6634.78 руб. | 6476 руб. |
| Jul-18-2025 | 5300.43 руб. | 5565.68 руб. | 5432.5 руб. |
| Jun-18-2025 | 6211.21 руб. | 6522.59 руб. | 6366.5 руб. |
| May-18-2025 | 5408.68 руб. | 5678.97 руб. | 5543 руб. |
| Apr-18-2025 | 6104.38 руб. | 6409.98 руб. | 6256.5 руб. |
| Mar-18-2025 | 6050.26 руб. | 6353.42 руб. | 6201.5 руб. |
| Feb-18-2025 | 5996.54 руб. | 6296.23 руб. | 6146 руб. |
| Jan-18-2025 | 5943.82 руб. | 6240.18 руб. | 6091.5 руб. |
Описание товара
Welcome to Curitis Automation Industry Co.,Ltd !
We promise to offer the best quality, competitive price,good communication, fast shipment and nice service.
80mm 25w Reduction Micro Ac Gear Motor Single-phase 50hz Ratio 18:1 Cheaper Price Replace Spg 80mm S8125GXCE/S8KA18B
Pls send us your needed voltage and gear ratio leave message.
Special Notifications about the motors:
1. If you choose 4IK25GN-C, you can only get the motor.
2. If you choose 4IK25GN-C 4GN K, you will get the motor and the gear head.
3. If you choose 4IK25GN-CT 4GN K, you will get the motor(With Terminal Box) and the gear head.
4. If you only need the gear head or Motor withTerminal Box, please contact me in advance.
Main Specs:
Motor | Motor with gearhead | |||||||
Model | Power | Voltage | Frequency | Current | Rated Torque | Gear Ratio | ||
4IK25GN-C | 25 | 1PH 220 | 50 | 0.25 | 200 | 18:1 | ||
Other voltage available for this model: 3phases,110V
Other gear ratio available for this model: 3:1, 3.6:1, 5:1, 6:1, 7.5:1, 9:1, 12.5:1, 15:1, 18:1, 25:1, 30:1, 36:1, 50:1, 60:1, 75:1, 100:1, 120:1, 150:1, 180:1;200:1
Pls send us your needed voltage and gear ratio leave message.
Induction Motors
25W
□80mm
■Specs /Continuous Rating
Model Type Below: Round Shaft | Output Power | Voltage | Frequency | Current | Starting Torque | Rated Torque | Rated Speed | Capacitor | |||
PLead Wire Type Dimensions ① | Teminal box type Dimensions② | W | V | Hz | A | mN.m | mN.m | r/min | μF | ||
4IK25GN-A (4IK25A-A) | 4IK25GN-AT (4IK25A-AT) | 25 | 1ph 100 | 50 | 0.500 | 120 | 200 | 1250 | 8.0 | ||
60 | 0.550 | 165 | 1550 | ||||||||
4IK25GN-E (4IK25A-E) | 4IK25GN-ET (4IK25A-ET) | 25 | 1ph 110 | 60 | 0.450 | 120 | 165 | 1550 | 7.0 | ||
1ph 120 | 0.550 | ||||||||||
4IK25GN-C (4IK25A-C) | 4IK25GN-CT (4IK25A-CT) | 25 | 1ph 220 | 50 | 0.250 | 120 | 200 | 1250 | 1.8 | ||
1ph 230 | 0.230 | ||||||||||
4IK25GN-H (4IK25A-H) | 4IK25GN-HT (4IK25A-HT) | 25 | 1ph 220 | 60 | 0.230 | 120 | 165 | 1550 | 1.8 | ||
1ph 230 | |||||||||||
4IK25GN-S (4IK25A-S) | 4IK25GN-ST (4IK25A-ST) | 25 | 3ph 220 | 50 | 0.185 | 350 | 200 | 1250 | ▪ | ||
60 | 0.170 | 250 | 165 | 1550 | |||||||
4IK25GN-S3 (4IK25A-S3) | 4IK25GN-S3T (4IK25A-S3T) | 25 | 3ph 380 | 50 | 0.106 | 350 | 200 | 1250 | ▪ | ||
60 | 0.098 | 250 | 165 | 1550 | |||||||
•When the motor is approved under various safety standards,the model name on the nameplate is approved model name. | |||||||||||
■Type
●Motor
Type | Model | |
Pinion Shaft | Round Shaft | |
Lead Wire Type | 4IK25GN-A | 4IK25A-A |
4IK25GN-E | 4IK25A-E | |
4IK25GN-C | 4IK25A-C | |
4IK25GN-H | 4IK25A-H | |
4IK25GN-S | 4IK25A-S | |
4IK25GN-S3 | 4IK25A-S3 | |
Terminal Box Type | 4IK25GN-AT | 4IK25A-AT |
4IK25GN-ET | 4IK25A-ET | |
4IK25GN-CT | 4IK25A-CT | |
4IK25GN-HT | 4IK25A-HT | |
4IK25GN-ST | 4IK25A-ST | |
4IK25GN-S3T | 4IK25A-S3T | |
●Parallel Shaft Gearhead(Sold Separately)
Gearhead Type | Gearhead Model | Gear Ratio | |
| 4GN□K | 3、3.6、5、6、7.5、9、1 0、12.5、15、18、20、2 5、30、36、40、50、6 0、75、90、100、120、150、180、200 | |
4GN10XK(Decimal Gearhead) | |||
•Enter the gear ratio in the box(□)within the model name | |||
■Allowable Torque When Being With Gearhead
•Gearhead and mid-gearbox can be sold separately. Enter the code that represents the terminal box type(T) in the box(□)within the model name.
•Enter the gear ratio in the box (□）within the model name.
•The colored background ▬ indicates the same rotating direction of the motor while the rotating direction of others are opposite.
•The speed is calculated by dividing the motor's synchronous speed(50Hz:1500r/min、60Hz:1800r/min)by the gear datio. The actual speed is 2%-20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the gear ratio in the table, attach a decimal gearhead(gear datio:10) between the gearhead and motor. In that case, the permissible torque is 8N•m.
■Allowance Torque Unit: Upside(N.m) Belowside(Kgf.cm)
Type | Gear Ratio | 3 | 3.6 | 5 | 6 | 7.5 | 9 | 10 | 12.5 | 15 | 18 | 20 | 25 | 30 | 36 | 40 | 50 | 60 | 75 | 90 | 100 | 120 | 150 | 180 | 200 | |||||
Speed | 50Hz | 500 | 417 | 300 | 250 | 200 | 166 | 150 | 120 | 100 | 83 | 75 | 60 | 50 | 41 | 37 | 30 | 25 | 20 | 16 | 15 | 12.5 | 10 | 8.3 | 7.5 | |||||
60Hz | 600 | 500 | 360 | 300 | 240 | 200 | 180 | 144 | 120 | 100 | 90 | 72 | 60 | 50 | 45 | 36 | 30 | 24 | 20 | 18 | 15 | 12 | 10 | 9 | ||||||
4IK25GN-A□ | 4GN□K | 50Hz | 0.49 | 0.58 | 0.81 | 0.97 | 1.20 | 1.50 | 1.55 | 2.00 | 2.40 | 2.90 | 3.17 | 3.70 | 4.40 | 5.30 | 5.57 | 6.60 | 7.90 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | ||||
5.00 | 5.91 | 8.26 | 9.89 | 12.2 | 15.3 | 15.8 | 20.4 | 24.4 | 29.6 | 32.3 | 37.7 | 44.9 | 54.1 | 56.8 | 67.3 | 80.0 | 80.0 | 80.0 | 80.0 | 80 | 80.0 | 80.0 | 80.0 | |||||||
60Hz | 0.40 | 0.48 | 0.67 | 0.80 | 1.00 | 1.20 | 1.25 | 1.70 | 2.00 | 2.40 | 2.64 | 3.00 | 3.60 | 4.30 | 4.49 | 5.40 | 6.50 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | ||||||
4.08 | 4.89 | 6.83 | 8.16 | 10.2 | 12.2 | 12.8 | 17.3 | 20.4 | 24.4 | 26.9 | 30.6 | 36.7 | 43.8 | 45.8 | 55.1 | 66.3 | 80.0 | 80.0 | 80.0 | 80.0 | 80.0 | 80.0 | 80.0 | |||||||
■Dimensions (Unit mm)
Mounting screws are included with gearhead.
●Lead Wiring Type ①
Weight: Motor: 1.6kg Gearhead: 0.80kg
Motor Model | Gearhead Model | Gear Ratio | L1 |
4IK25GN-A | 4GN□K | 3-200 | 43.5 |
4IK25GN-E | |||
4IK25GN-C | |||
4IK25GN-H | |||
4IK25GN-S | |||
4IK25GN-S3 | |||
•Enter the gear ratio in the box(□)within the model name. | |||
●Terminal Box Type ②
Weight: Motor: 1.75 kg Gearhead: 0.80kg
Motor Model | Gearhead Model | Gear Ratio | L1 |
4IK25GN-AT | 4GN□K | 3-200 | 43.5 |
4IK25GN-ET | |||
4IK25GN-CT | |||
4IK25GN-HT | |||
4IK25GN-ST | |||
4IK25GN-S3T | |||
•Enter the gear ratio in the box(□)within the model name. | |||
●Key Keyway (Accessories of Gearhead)
●Shaft Section Of Round Shaft Type
Excluding weight and the shaft section motor shape are the same as those of the pinion shaft type.
●Decimal Gearhead
Can be connected to GN pinion shaft type
4GN10XK
Weight: 0.41kg
■Formal Dimension Of Capacitor
Model | Capacitor Model | L | W | H | |
Pinion Shaft | Round Shaft | ||||
4IK25GN-A□ | 4IK25A-A□ | ZD80CFAUL | 48 | 26.5 | 38 |
4IK25GN-E□ | 4IK25A-E□ | ZD70CFAUL | 47 | 24.0 | 37 |
4IK25GN-C□ | 4IK25A-C□ | ZD18BFAUL | 36 | 13.5 | 24 |
•Note: Conventioal capacitor is a lead wire type. Inserted 187# is optional Enter the code that represents the terminal box type "T" in the box(□) within the model name | |||||
■Wiring Diagram
•The direction of motor rotation is as viewed from the shaft end of motor. CW represents the clockwise direction, while CCW represents the counterclockwise direction.
•Name indicated in the list is pinion shaft type, also valid for the equivalent round shaft type.
Note:
•Change the direction of single-phase motor rotation only after bring the motor to a stop.
•If an attempt is madeto change the direction of rotation while the motor is rotating,motor may ignore reversing or change its direction of rotation after some depaly.
● Special Declaration:
• Please read carefully about the descriptions of the products and if any questions, contact sales immediately. For products that sold out, if it is not quality problem, can not return the goods and money.
• Please check carefully about the packing and open to check if products are good. If package is broken or there is problems of the products, don't sign in.
• Please contact sales for more information and confirm about details about products. And in case of potential problems.
How about other ac motor styles can production ?
AC Gear Motor
* Motor Type: Induction/Reversible/Break/Torque/Speed Control Motor
* Frame Size:60mm, 70mm, 80mm, 90mm, 104mm
* Power:6W-200W+
* Ratio Range:3-200K
* Voltage:110V/200V/220V/380V/415V 50/60Hz Single/Three-Phase
* Application:Packing Machinery, Barrier Gate System, Conveyor and ect.
| MOTOR FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | |||
| MOTOR TYPE | INDUCTION MOTOR / REVERSIBLE MOTOR / TORQUE MOTOR / SPEED CONTROL MOTOR | |||
| OUTPUT POWER | 6W / 10W / 15W / 25W / 40W / 60W / 90W / 120 W / 140W / 180W / 200W(can be customized) | |||
| OUTPUT SHAFT | 8mm / 10mm / 12mm / 15mm ; round shaft, D-cut shaft, key way shaft(can be customized) | |||
| Voltage type | Single phase 100-120V50/60Hz 4P | Single phase 200-240V 50/60Hz 4P | ||
| Three phase 200-240V50/60Hz 4P | Three phase 380-415V 50/60Hz 4P | |||
| Three phase 440-480V60Hz 4P | Three phase 200-240/380-415/440-480V 50/60/60Hz 4P | |||
| Accessories | Terminal box type / with Fan / thermal protector / electromagnetic brake | |||
| Above 60 W, all assembly with fan | ||||
| GEARBOX FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | |||
| GEAR RATIO | MINIMUM 3:1---------------MAXIMUM 750:1 | |||
| GEARBOX TYPE | PARALLEL SHAFT GEARBOX AND STRENGTH TYPE | |||
| Right angle hollowworm shaft | Right angle spiralbevel hollow shaft | L type hollow shaft | ||
| Right angle solidworm shaft | Right angle spiralbevel solid shaft | L type solid shaft | ||
