PIR switch specifications

Description:

Automatic control based infrared technology, high sensitivity and high reliability, intelligent, user-friendly,

Switches unipolar designs, direct replacement remote control switch, manual switch, voice-activated switch

Touch switch. Without any alteration of the original layout, easy to use, can be accessed by all sorts of lighting, exhaust fans

Members.

Scope of application:

The switch can load incandescent lamps (light bulbs) and energy-saving lamps LED light ring lamp, fluorescent lamps and other light sources, widely applicable: guesthouses, hotels, offices, factories, warehouses, residential garages, stairs, walkways, entrances, bathrooms, elevators and other public places, matching lamps are used. A great choice for lighting switch.

Features:

1.    Automatic induction

People come to light, delay time, those lights. Energy saving and environmental .

2.    Automatic metering

3.    Photo control,Under daylight or light not induction,At night or under low light sensor.(Also can be done throughout the day and can detect)

4.    Automatic delay

Switch once connected, if a person switches within the range of reaction activity has been switched . If people leave the range of reaction by a last time before leaving for the datum point, start delay (delay time see technical data) prevail, this switch is not adjustable fall light. Delay time to switch through the variable resistor to set the time of the.Generally20Seconds-40Seconds)

Technical parameters:

Product model:AD01-R1

Product specifications:75X38X28MM

Working voltage:AC180V-240V(50/60HZ)

Output type: relay

Load power:200W

Sensing distance:The 3-5M

Sensor angle:120Degree

Start the brightness L:L&;5Lux (equivalent to a sunny day at the sky brightness),

Delay time: 20-40 seconds

Apply light source: incandescent lamps, energy saving lamps, LED lights, fluorescent circular lamps and other lamps.

Instructions for use:

1.      Please click loaded casing wiring diagram switch,Power for one minute after initialization time,At the initialization time switch switching for indeterminate state,Continuous Flash three times,One minute into a functional State,Check the switch during the day is normal,May be covered or occlusion with black switch,Light dimming,Conducting light.

2.      Set delay time delay and sensitivity to the factory and luminosity are subject(See in particular technical parameters)The switching delay time cannot be adjusted and luminosity.

3.      When installing the switch,Do not mount the switch position of the import and export of strong and hot and cold air,Should not be packed in too noisy environments using.Otherwise it will false positive signals and lights,Unable to save energy.

4.      This switch permits parallel access,But you need to pay attention to the power problem,Is greater than the product a certain load.This switching of load power tests are normal,Load power indicated below can prolong the life of the switch.

Notes:

1.      Installation disconnect the power supply when,Ensuring security.

2.      Banned power scope of application.

3.      The location cannot be installed the water to.

4.      Detection range varies with ambient temperature. Detection distance is shorter in the summer, (when body temperature is close to the most obvious), winter range quite far.

5.      Cannot be installed less than-20Degree and above60The location of.

6.      Please do not position in the Sun.

7.      Recommendations do not install in a location with an active object.

After-sales service:

All products can be purchased in our company warranty18A month.If the product after purchase1Problems with performance within one month,And no appearance damage,Draw flowers,Direct replacement of the product.

Under the following circumstances don't belong to the warranty scope:

1.      Not according to the instructions required to install,Use,Maintenance,Keep product failure or damage caused by.

2.      Has outside of the warranty period.

3.      Unexpected factors or human behaviour lead to damage,If input is not suitable for voltage,Load beyond the prescribed power.High temperature,Water inlet,Broken,Not according to the wiring diagram instructions installation and burn products.

This product has been inspected YRS lighting factory Zhongshan guzhen, Guangdong Province.Please rest assured purchase using!
