What’s in Box?

• 2 × PrimoPal's NEMA 24 Hybrid Stepper Motor, MPN PHB60S64-43056-8D • 2 × PrimoPal's Stepper Motor Driver, MPN PSR5042 • 1 × Mean Well's Switching Power Supply, MPN NES-200-36 • 1 × Breakout Board & DB25 cable (for-free offering)     Stepper Motor Description This stepper motor (MPN PHB60S64-43056-8D) is supplied by one of the China's top stepper motor suppliers (PrimoPal Motor). It's a bipolar NEMA 24 hybrid stepper motor with 1.8° step angle (200 steps/revolution), made of high-quality cold roll sheet copper and anti-high temperature magnetic steel. The rated current is 3.0A per phase, allowing for the holding torque of 180Ncm (255oz-in). This high-performance and high-reliability motor is terminated with 4 flying ended lead wires, and easily connected to the constant current or chopper drive controller.     Stepper Motor Specifications • Electrical Specs

  • Physical Specs

  • Wiring Diagram





Stepper Motor Driver Description This stepper motor driver PSR5042 is supplied by one of the China's top stepper motor drive suppliers (PrimoPal Motor). PSR5042 is a high-performance microstepping drive based on pure-sinusoidal current control technology. Owing to the above technology and the self-adjustment technology (self-adjust current control parameters) according to different motors, the driven motors can run with smaller noise, lower heating, smoother movement and have better performances at higher speed than most of the drives in the markets. It is suitable for driving 2-phase and 4-phase hybrid stepping motors. PSR5042 is suitable for a wide range of stepping motors, from NEMA size 17 to 24. It can be used in various kinds of machines, such as X-Y tables, engraving machines, labeling machines, laser cutters, pick-place devices, and so on. Particularly adapt to the applications desired with low noise, low heating, high speed and high precision.   Key Features:     Stepper Motor Driver Specifications • Electrical Specs

  • Pin Assignment and Description

This stepper motor drive PSR5042 has two connectors, connector P1 for control signals connections, and connector P2 for power and motor connections. The following tables are brief descriptions of the two connectors.



Connector P1 Configurations

  Connector P2 Configurations   • Microstep Resolution Selection



• Dynamic Current Setting



• Outline Drawing                                                            • Typical Connection







Power Supply Description This switching power supply (MPN NES-200-36) is supplied by one of the world's top power supply suppliers (Mean Well).   Key Features: • AC input range selectable by switch
• Protections: Short circuit / Overload / Over voltage / Over temperature
• Cooling by free air convection
• Withstand 300VAC surge input for 5 seconds
• Built-in constant current limiting circuit
• LED indicator for power on
• Fixed switching frequency at 90KHz
• 100% full load burn-in test
• Low cost, high reliability
• 2 years warranty     Power Supply Specifications     • Mechanical Drawing





Breakout Board Description Key Features • Can connect 6 drives and control 6 motors at the same time. • Built-in DB25 female connector. • DB25 connector output pinout: P1~P9, P14, P16, P17. • DB25 connector input pinout: P10~P13, P15. • DB25 GND pinout: P18~P25. • +5VDC power supply can be connected. • Support MACH3 software. • Built-in optical-coupler.   Output & Input Signals

Output Signals



Input Signals

• P10~P13, P15 - could be set for emergent stop and X, Y, Z limit switch



    Transaction Terms • Shipping Time and Terms



• Payment Terms



• Warranty & Refund



• Leaving Feedback to Us
