Kingdel New arrival Fanless Mini Industrial Computer Barebone Intel i7 5550U 4500U 8G RAM Desktop PC Win 10 Dual LAN 6 Com RS232 |

---

4500U or 5500U will be delivered at random

Mini Industrial Computer, Desktop PC



intel i7-5550U Dual Core Turbo up to 3.0GHz 4MB Cache

2*HDMI, 2*Gigabit LAN, 4*USB3.0, 4*USB2.0, 6*COM RS232

intel HD Graphics 6000, Low Power Consumption WiFi, Fanless





Kindly Reminded:

  1, This computer only works with RAM at lower voltage 1.35V instead of normal 1.5V RAM. 2, Warranty is 3 years for Barebone PC, 1 Year for RAM and Storage. 3, The RAM and SSD/HDD are from famouse brand, the RAM is normally Sam'sung, Elp'ida, Hynix; The SSD is normally from Tosh'iba, Sam'sung, ADATA, Intel, Lite-on etc. they will be shipped out at random for stock. 4, The Operating System is just for testing, copied and activated but not licensed, please install the licensed one by yourself if you prefer. 5,  Please carefully read the SHOPPING GUIDELINES   on the bottom of this page. It is regarded as you have agreed all listed when you place an order. We won't take responsibility for any problems might caused except the quality problem of the product.   Thank you !   Windows 10 Desktop:

Wireless Mini Keyboard on sale for this mini computer:









Branded Spare Parts, Boyscott Fake Parts!!

Top Quality, 3 Year Warranty, Rest Assured!!





1,Quality Approval:



2, Features & Benefits:



CPU: Intel®  Core™ i7-5550U Processor (4M Cache, 2.0GHz, Max Turbo Frequency 3.0 GHz) Graphics: Intel HD Graphcis 6000, support HDMI resolution 2560x1600@60Hz      RAM: Support DDR3L 1600MHz, max expanded to 8GB DDR3L-1333/1600MHz SODIMM Notebook memory;      Storage: max expanded to 1*mSATA3 SSD and 1*2.5 inch laptop HDD SATA3, no limited on storage capacity;   Operating System: Default: Windows 10 Pro; Optional: Windows 7, Windows 8.1 & Linux Ubuntu   Language: Multi Language available; USB port: 4*USB 3.0, 4*USB 2.0; Serial Port: 6* RS232 COM;
Parallel Port: no, support external USB to Parallel Port adapter; Feature: Fanless Wireless: 300MB WiFi with 2 Antennas HD Out put: 2*HDMI port, maximal support Blu-ray 1080P resolution; LAN port: 2 Gigabit RJ45 port;       3, Specifications:

Processor	Core i7-5550U
Speed	2.0~3.0GHz, 4MB Cache
Processor number	2 core / 4 threads
Technique	14nm
Graphic Cards	Intel HD Graphics 6000
Graphics Base Frequency	300MHz
Max Dynamic Frequency	1GHz
Resolution (MAX)	2560x1600@60Hz
Operating System	Default: Windows 10; Optional: Windows 8.1/ Windows 7/ Linux Ubuntu
Storage	32GB/64GB/128GB/256GB SSD; 500GB/1TB HDD available
RAM	DDR3L 1333/1600; 1*DDR3 Slot; 2gb/4gb/8gb optional
Audio Cards	ALC662 sound chip, 6-channel
Network card	RTL8111DL PCI-E Gigabit Ethernet NIC
Ethernet	10/100/1000mbps BaseT LAN
WIFI	dual antenna, 802.11.b/g/n 300M
Display port	2* HDMI
USB port	4 * USB 3.0, 4 * USB2.0
Ethernet port	2* RJ45 10/100/1000Mbps Adaptive
Industrial Port	6* RS232 COM Port
Power input port	1 inner diameter 2.5mm, external diameter 5.5mm
Audio	Standard 3.5 Audio input and output
Power Input	DC100-240V AC/50-60Hz
Power Output	DC 12V/6A
Power Type	External power adapter mode
Consumption	15-25W
Noise	Fanless System
Temperature	0-95 Centigrade
Humidity	10%-90%
Size	235*150*50mm
Case Thickness	2.9MM
Package Box	Neutral Color Export Box / Plain Box
Content	Mini Computer, Power Adapter, Power Cable, screws, WiFi Antennas



4, What can this mini computer do?

  1. Office work: Office, skype, yahoo, outlook and all other office requirement support and runs perfect; 2. Design work: Photoshop, CoreIDRAW, Dreamweaver, IIIustrator, Flash, Indesign and others 3. Game playing: support most online games and PC games, like Warcraft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games. 4. Entertainment: support blue ray 1080P video play, XBMC and others.

5, Product Photos:
