CE Passed

2018 New  220V Water Acrylic Flame Polishing Machine Polisher Welder Torch 75L

( This model the electrolysis jar is made of stainless steel, which is more strong and different from the old model.)

We also have the 110V for sale. Please contact us to buy.

Using method

1)     Prepare electrolyte:

Pour 2000cc distilled water (or pure water) into a made of glass, china or heat-resistant plastic (warning: aluminium container is prohibited). Put 0.1kg electrolyte power into the water slowly, stir until it is dissolved completely. It generates heat while dissolving, and need to be cooled for about 20 minutes.

2)     Add electrolyte:

Screw off the top cover, add electrolyte into the generator carefully until the water level close to the “hight” line, then screw on the cover.

3)     Prepare the gas filter:

Screw off the gas filter, add ethanol or nothing, then screw it on. Ethanol (alcohol) of 70%above is for fire-polishing acryl (organic glass), because the mixture of hydrogen and ethanol volatile can lower the flame temperature. The remaining ethanol should be poured out of the gas filter everyday after use. You may add nothing in the gas filter.

4)     Switch on and check:

Switch on the power, the indicator light turns bright, the fan begins running; gas can be felt out of the outlet (within 1 minute), the barometer indicates0.01-0.05mpa. If you seal it with a finger, the gas pressure will go up until over 0.1mpa and the ammeter indicates zero; move out the finger, the gas pressure will go down and the ammeter indicates well.

5)     Link the rubber pipe and torch and ignite:

Link the rubber pipe and torch to the gas outlet. Hold the torch and open the valve on the torch, then ignite and observe the color of flame. The normal color is light blue. The valve can be adjusted to control the flam. To change a torch, you should torch off the valve to extinguish first.

For fire-polishing acryl, choose a suitable torch, let the flame 45 degree to the coarse surface of acryl and move it parallel. Anyone can use it adroitly after several hours of practice.

6)     Add water timely:

After several hours of operation, the water level may fall below the “middle” line, and the ”fuel”-water should be added. Distilled water is the best choice, then is the best choice, then is purified water, cold boiled water and mineral water is the best choice, then is purified water, cold boiled water, tap water and mineral water, orderly.

Attention:

Please turn off the flame gun first, then turn off the power when you want to stop working.
