Factory direct 155Mb/s 1*9 Single-Mode Transceiver 1X9 Pin Package Duplex ST +3.3/5V 1310nm FP SM 20KM Optical fiber module | Мобильные

1X9 155M 1310nm 20km 3.3/5V ST connector

Quantity: 1 piece

1x9 Transceiver is a high performance, cost effective module for optical data communication applications. All versions are compliant with SONET/SDH recommendations from OC-01 to OC-03. This module is designed for Single-Mode fiber and operates at the normal wavelength of 1310 nm. The transmitter section incorporates an advanced FP and driver IC with temperature compensation and automatic power control circuit. The receiver section incorporates an efficient InGaAs/InP PIN photodiode and transimpedance with AGC for wide dynamic range. The transceiver has excellent immunity and reliability

• 1X9 Pin Package, Single-Mode Transceiver
• SC/FC/ST receptacle or FC pigtailed single mode optical interface
• Single 3.3/+5V Power Supply
• Fully Compliant with ITU-T G957, G958 Specification
• PECL Logic Interface
• Class 1 Laser Product, Compliant with IEC 60825-1
• Compliant with Telcordia (Bellcore) GR-468-CORE
• RoHS Compliant Products Available

• SONET/SDH/PDH
• ATM
•
•
