I-NUCLEO-LRWAN1 STM32 LoRa Extension Board expansion board module

Product: Evaluation Boards Type: RF Amplifiers Evaluation tools: STM 32l052t8y6 Frequency: 860 MHz to 1020 MHz Working power supply voltage: 2 V to 3.6 V Function: LoRa expansion board for STM32 Nucleo For: STM 32l052t8y6 Interface Type: USART High operating temperature: + 85 C Low operating temperature: -40 C Series: STM32 NUCLEOSTMicroelectronics I-NUCLEO-LRWAN1STM32 LoRa™Arduino expansion boardSTMicroelectronics I-NUCLEO-LRWAN1 STM32 The LoRa™Arduino Expansion Board is a suite of integrated solutions for the development of projects using Lora and/or FSK/ook technologies. I-NUCLEO-LRWAN1 with USI LoRaWAN technology module, can be preloaded embedded AT command stack. Equipped with Level A certified embedded software (I-CUBE-LRWAN), can be used to build a complete LoRaWAN node. The I-NUCLEO-LRWAN1 expansion board includes the USI LoRaWAN module, the Arduino connector, the SMA connector, the 50-ohm antenna and three STMicroelectronics environmental sensors. Three internal sensors are LSM303AGR: Accelerometer and Magnetometer, HTS221: Relative Humidity and Temperature Sensors, and LPS22HB: Pressure Sensors. feature of productUltra-low power STM32L0 series MCU, equipped with Cortex®-M0 + core, built-in 64KB flash memory, 8KB RAM, 2KB EEPROM and T-RNGUp to 157dB link budgetSupply+ 14dBm high efficiency PAProgrammable bit rate up to 300kbpsHigh sensitivity: lowest -137dBmFront end bulletproof: IIP3 = -12.5dBm89dB anti-blocking ability Low RX current 10mA, 200nA temporary register retentionFully integrated synthesizer with resolution up to 61HzFSK, GFSK, MSK, GMSK, LoRa™And ook ModulationBuilt-in bit synthesizer for clock recoverySynchronous word recognitionLeading detection127dB + dynamic range RSSIBuilt-in temperature sensor and low battery indicator,1.8V to 3.6V power supply
