Receiver

Channel: 8CH

Control Types: Toggle, Momentary, Latched

Decode: Learning code

Frequency:315MHz/433MHz

Power Supply (Operating Voltage): DC12V

Relay: 10A/120VAC, 10A/277VDC

Work Voltage Range of Relay: AC 110~240V or DC 0~28V


Transmitter

Channel: 8CH

Distance: 100 meter(open/ideal) in theory, 10%-50% in reality(In open environment,receiver antenna outside the box)

Encode: Fixed code, Soldering

Size: 125mm x 49mm x 20mm

Power Supply: 1 x 23A-12V battery

Function

Learning Codes

Press the learning button on the receiver ,when hear BI sound,it means enter into learning status,then press the relative button on the remote,when hear 3 sounds BI BI BI,it means learn successfully.

Clear Codes

Press the learning button on the receiver about 10 seconds,when hear BI sound again, it means the codes are cleared.

 1. Jog/momentray: Press one button is Working /ON.  Loosen your finger on the same button is Stop/OFF.  One channel switch need one buttons remote control.

2.Self -lock/Self-Latched: Press one button for one time is working/ON.  Press the same button again is stop/OFF.  One channel switch need one buttons remote control.

 3.Inter-lock /Latched: Press one button is working/ON, press another button is stop/OFF.  One channel switch need 2 buttons remote control.

Work model:

 8 CH Momentary--------1 Button to learn  (Momentray default,

8 CH inter-lock ------2 Button to learn

8CH Self- Lock --------3 Button to learn

Package

1 X Receiver

1 X Transmitter(Include battery)
