H2 Portable Gas Analyzer PGAS-21-G-H2 Pump-priming Professional Precise Hydrogen Detector Tester 0-2000ppm Monitor | Инструменты

---

H2 Portable Gas Analyzer PGAS-21-G-H2 Pump-priming Professional Precise Hydrogen Gas Detector Tester 0-2000ppm Gas Monitor

Note : That this product has four measurement ranges, 0-1000/2000/10000/40000ppm, please let us know if you need a different one.     Brief Introduction PGas-21-G Pump-priming Portable Gas Detector Is a continuous monitoring of a variety of single gas detection equipment. This product is suitable for environmental monitoring, industrial production and other harmful gases working environment, which can effectively protect the health and safety of staff is not compromised. They are widely used in petroleum chemical industry, power industry, water treatment industry, the tobacco industry, pharmaceutical industry, food industry, coal, metallurgy, municipal gas, environmental monitoring and other occasions on-site testing.   Main features 1.Smart probe design, calibration 2.Maintenance more convenient in the future; 3.Fault, Warning, operator error, alarm will be smart tips; 4.Built-in CF calibration coefficients (VOC measurements only valid); 5.With audible alarm, visual alarm function, the status bar also displays alarm status; 6.Full-color 3.5-inch TFT screen, color LCD display and intuitive; 7.Can be both digital and curve display of gas concentration in two ways; 8.With USB communication port, you can speed 9600 bytes to communicate directly with the computer; 9.With test record function, can store a month's measurement data and instrument or computer can view the data; 10.With alarm recording function, you can record the last four times the alarm time and type; 11.With calibration record; can record the last four times the size of the calibration time span; 12.High-capacity lithium battery-powered, rechargeable, low battery automatic shutdown; 13.Can be set high reported, underreporting, TWA, STEL, shutdown time, pump speed, etc.;



Technical Parameters
Parameters	Characteristics
Detected Gas	flammable gases, oxygen gas and many kinds of toxic & harmful gases.(Please refer to the Lectotype table)
Power supply	Lithium battery (4.2V/3000mAh)
Operating Current	normal current: ≤ 150mA; Alarm current: ≤ 200mA
Operating environment	Temperature: -40 ℃ - 70 ℃
	Relative Humidity: 15% - 95%, non-condensing
Storage environment	Temperature: -20 ℃ - 60 ℃
	Relative humidity: ≤ 90%, no condensation
Housing material	PC
Dimensions	228 * 84 * 50.5mm
Installation	Handheld / Stand-in
Weight	0.55 kg



Model	Detected gases	Range	Measurement Principle
PGAS-21-G-CH2O	CH2O	0-10/50/500/1000ppm	Electrochemical
PGAS-21-G-CH4	CH4	0-5%/0-10%/0-100%VOL	Infrared
PGAS-21-G-NO2	NO2	0-25/100/1000/2000ppm	Electrochemical
PGAS-21-G-SO2	SO2	0-20/100/500/1000/2000ppm	Electrochemical
PGAS-21-G-SF6	SF6	0-1000/2000/3000ppm	infrared principle
PGAS-21-G-ETO	ETO	0-20/100/5000ppm	Electrochemical
PGAS-21-G-FL	FL	0-5%VOL /0-100%VOL	infrared principle
PGAS-21-G-HCL	HCL	0-20ppm	Electrochemical
PGAS-21-G-PH3	PH3	0-5/20/200/1000/2000/4000ppm	Electrochemical
PGas-21-G-CO	CO	0-200/500/1000/2000/5000/10000ppm	Electrochemical
PGas-21-G-CO	CO	0-10%/20%/50%/100%vol	Infrared
PGAS-21-G-VOC	VOC	0-20 ppm	PID
PGAS-21-G-VOC	VOC	0-200 ppm/0-2000/10000 ppm	PID
PGAS-21-G-HCN	HCN	0-20/100 ppm	Electrochemical
PGAS-21-G-CO2	CO2	0-5%/10%/20%/50%/100%vol	infrared principle
PGAS-21-G-LEL	LEL	0-100%LEL	Electrochemical
PGAS-21-G-C2H4	C2H4	0-10/200/1500ppm	Electrochemical
PGAS-21-G-H2	H2	0-1000/10000/40000ppm	Electrochemical
PGAS-21-G-SF6	SF6	0-1000/2000/3000ppm	infrared principle
PGAS-21-G-H2S	H2S	0-50/100/200/1000/2000/5000ppm	Electrochemical
PGAS-21-G-O2	O2	0-25%vol	Electrochemical
PGAS-21-G-NO	NO	0-100ppm	Electrochemical
PGAS-21-G-CL2	CL2	0-20/200/2000/5000ppm	Electrochemical
PGAS-21-G-NH3	NH3	0-100/1000/5000ppm	Electrochemical
PGAS-21-G-H2-A	H2	0-1000ppm	Electrochemical
PGAS-21-G-O3	O3	0-5/10/20/50/100/200/1000/5000/30000ppm	Electrochemical
PGAS-21-G-F2	F2	0-10ppm	Electrochemical
PGAS-21-G-HF	HF	0-10ppm	Electrochemical
PGAS-21-G-HBr	HBr	0-20ppm	Electrochemical
PGAS-21-G-COCL2	COCL2	0-20ppm	Electrochemical
PGAS-21-G-SIH4	SIH4	0-50ppm	Electrochemical
PGAS-21-G-CLO2	CLO2	0-20 ppm	Electrochemical
PGAS-21-G-H2O2	H2O2	0-100/500/2000 ppm	Electrochemical
PGAS-21-G-CO	CO	0-10%/20%/50%/100%vol	infrared principle
PGAS-21-G-CO2	CO2	0-2000/5000ppm/1%/5%/20%/50%/100%vol	infrared principle
