NT68676(HDMI+DVI+VGA) LCD Driver Monitor Kit for LED Display LP156WH3(TL)(SA) 1366X768

     This is a great set of easy-reassembling LCD controller kit which is used to turn a bare LCD panel into a desktop/PC monitor. It will be a surprise that your bare LCD will be of good use, and no longer be a waste. Or it is a very insteresting things that we make a monitor successfully by ourselves.  Plug&play kit, no need soldering.

     Necessary Accessories for turning these bare LCDs to desktop monitor: LCD Controller board, LVDS cable, Keypad, VGA cable/DVI Cable/HDMI cable, Power Adapter. If you have already had a VGA cable/DVI cable/HDMI cable and a power adapter (Ouput 12V,4A ), this kit is a great choice for you;.

 About the LCD Controller Board  M.NT68676.2A in this kit:

M.NT68676.2A is a monitor control board, which can support LED/LCD panels. It can support resolution up to 2048X1152.

M.NT68676.2A can synchronize with computer automatically. Synchronization requires the synchronous signal which horizontal and vertical sync are separated.

M.NT68676.2A can support dynamic contrast control, headphone input and digital volume control simultaneously.

Size of controller board: 139mmX58mmX17mm

    Have a try and you will get great surprise !

  Then, are you going to get this kit ?

   Notes:

   1. Please make sure that your LCD is ok before bidding this item, else you will be responsible for the incompatibility.

  2. If you are not specialized in electronics or have doubts in operation, please contact us for instruction, as we are not able to responsible for wrong operation.

Instruction to connect the controller board to the LCD:

1. Take away the old inverter and old LVDS cable from the LCD panel.

2. Connect the LVDS cable to your LCD panel.

3. Connect controller board with PC by VGA cable/DVI cable/HDMI cable.

4. Input power of 12V,4A. ( Please don't revised the voltage jumper setting on the lcd controller board before confirmation from us, because wrong revising of this voltage will get your lcd burnt. By the way, please don't connect the lvds cable wrongly, some wrong connecton can get your lcd burnt too, if you are not sure, please feel free to contact us. )

Package Include:

• 1 X LCD Controller Board (M.NT68676.2A) programmed for LP156WH3(TL)(SA)
• 1 X 5 keys Keypad with jumper cable
• 1 X LVDS cable

    Welcome to customize your own kit if your lcd model number is not in the list!
