Характеристики
TUF-2000B with Transducer TL-1 (DN300-6000mm) PT-100 (CT-1) heat sensor digital liquid ultrasonic flowmeters flow meter | Инструменты
История изменения цены
*Текущая стоимость US $259.58 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Aug-16-2025 | 329.92 руб. | 336.29 руб. | 332.5 руб. |
| Jul-16-2025 | 267.44 руб. | 272.84 руб. | 269.5 руб. |
| Jun-16-2025 | 324.77 руб. | 330.95 руб. | 327 руб. |
| May-16-2025 | 321.58 руб. | 327.10 руб. | 324 руб. |
| Apr-16-2025 | 256.19 руб. | 261.48 руб. | 258.5 руб. |
| Mar-16-2025 | 316.93 руб. | 322.38 руб. | 319 руб. |
| Feb-16-2025 | 313.33 руб. | 319.33 руб. | 316 руб. |
| Jan-16-2025 | 311.82 руб. | 317.23 руб. | 314 руб. |
Описание товара
TUF-2000B with Transducer TL-1 (DN300-6000mm) PT-100 (CT-1) heat sensor digital liquid ultrasonic flowmeters flow meter
Introduction of Ultrasonic flow meter:
TUF-2000B Flowmeter can be virtually applied to a wide range of long-term online measurement. Convertor protection class IP67,transducer protection class IP98.A variety of liquid applications can be accommodated: ultra-pure liquids ,portable water,chemicals,raw sweage,reclaimed watere,cooling water,river water,plant.etc
Performance and Parameter:
Performance &Parameter | ||
Convertor | Principle | Transit-time ultrasonic flowmeter |
Accuracy | ±1% | |
Display | 2x20 character LCD with backlight, support the language of Chinese, English, Italy, Turkish | |
Signal output | 1way 4-20mA output, electric resistance 0-1K, accuracy0.1% | |
1 way OCT pulse output(Pulse width-1000ms, default is 200ms)) | ||
1 way Relay output | ||
Signal input | 3 way 4-20mA input, accuracy 0.1%, acquisition signal such as temperature, press and liquid level | |
Connect the temperature transducer P100, can finish the heat/energy measurement. | ||
Data Interface | Insulate Rs485 serial interface, upgrade the flowmeter software by computer, support the MODBUS. | |
Special Cable | Twisted-pair cable, generally, the length under 50 meters, select the Rs485, transmission distance can over 1000m | |
Pipe Installation Condition | Pipe material | Steel, stainless steel, cast iron, copper, cement pipe, PVC, Aluminum, glass steel product, liner is allowed |
Pipe diameter | 25-6000mm | |
Straight pipe | Transducer installation should be satisfied: upstream10D, downstream5D, 30D from the pump. | |
Measuring Medium | Type of liquid | Single liquid can transmit sound wave; such as water (hot water ,chilled water, city water, sea water, waste water, etc); sewage with small particle con tent, oil(curde oil, lubricating oil, diesel oil, fuel oil, etc); chemicals(alcohol, etc); plant effluent; beverage; Ultra-pure liquids, etc |
Temperature | -30-160℃ | |
Turbidity | No more than 10000ppm and less bubble | |
Flow rate | 0-±7m/s | |
Temperature | Convertor; -20-60℃; Flow Transducer: -30-160℃ | |
Humidity | Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m | |
Working Environment | Temperature | Convertor; -20-60℃; Flow Transducer: -30-160℃ |
Humidity | Convertor: 855RH; Flow Transducer: can measure under water, water depth≤2m | |
Power Supply | DC8-36V or AC85-264V(Optional) | |
Power Consumption | 1.5W | |
Dimension | 132*150*85mm(convertor) | |
2 x 5m Flow Signal CableOptional Transducers:
If you need other transducer or extend the signal cable length, please contact us.
Optional temperature transducers PT100:
NOTE: SD VERSION, extra $35/pcs COST.
