Xiaomi Aqara Wall Switch Light ZigBee Device APP Wireless Smart Control Work with Mi Sensors Home Automation | Электроника

---

Xiaomi Aqara Wall Switch Light Switch ZigBee Device APP Wireless Smart Control Work with Mi Sensors Xiaomi Smart Home Automation

  Specifications   *Xiaomi Aqara wall switch(single firewire) ZiGBee version *Input: 220V～, 50Hz for single live line *Dimension: 86*86*15.12mm *Load range: no more than 800W / circuit, 3W energy saving lamp / 5W LED lamp / 16W fluorescent lamp at minimum *Wireless connection: ZigBee *Can connect to Aqara smart device or other ZigBee device *Working temperature: 0 - 40 Deg.C  *Working humidity: 5 - 95 pct  *Please download the "Mi Home"APP in Google Play or APP Store     What is included   1 x Xiaomi Aqara wall switch(single firewire) ZigBee version

Product Details

    Aqara smart three-way switches vs. standard three-way switches   Easily upgrading without replacing the original lamps   Aqara Wall Switch can be easily and rapidly installed without changing the original lighting equipment and circuit. Commonly-used lamps can be flexibly controlled. Only by replacing the traditional Wall Switch with an Aqara Wall Switch.   Match Aqara Wall Switch with Mi sensors  to achieve various functions   You can match Aqara's Wall Switch with other Mi Sensors to achieve various functions. More ZigBee devices connected to the system means a better user experience.   High-quality Wall Switch   The Aqara Wall Switch, when matched with a Panasonic 16A Pickup Resistance Relay, can control lamps from 3W to 1500W. Equipped with atemperature detection chip and 5A fuse, it can automatically shut off when detecting a load greater than 1500W or the internal temperature exceeds 60 degrees Celsius. The panel can be switched up to 50,000 times.   Instructions for installation   Each rocker of the Wall Switch (Aqara Double Rocker Switch) controls one lamp. The switch can be installed in the following steps:   1. Turn power off at the circuit breaker, remove switch cover plate, remove existing switch, replace with Aqara Double Rocker Switch, connect live wire of wall junction box to Input Terminal L, then connect the lamp wire of wall junction box to L1 and L2 (Note: The lamps connected with L1 and L2 are controlled by the left button and right button respectively), and finally tighten the screw. See the drawing below for wiring:     2. Remove the switch panel with straight screwdriver.     3. Secure the switch on the wall junction box with screw.     4. Press down the switch panel.     5. Turn on the main switch. You can confirm the Aqara Wall Switch is powered-on if the blue status indicator flashes once. Press the button, the switch is functional but not connected to a network when the red state indicator flashes slowly.   Download the client and install it according to the steps of “add device”.
