A2D210-AB10-05 Germany Ebm-Papst New OuterRotor 210 Size Siemens Servo Spindle Motor AC Cooling Axial Fan With Sickled Blades |

Nominal data

Motor

M2D068-CC

Phase

3~

3~

Nominal voltage

VAC

200

200

Connection

Δ

Δ

Frequency

Hz

50

60

Type of data definition

fa

cu

Valid for approval / standard

CE

CE

Speed

min-1

2700

3050

Power input

W

64

86

Current draw

A

0.33

0.31

Min. ambient temperature

°C

-25

-25

Max. ambient temperature

°C

90

90

Starting current

A

0.94

0.92

ml = Max. load · me = Max. efficiency · fa = Running at free air · cs = Customer specs · cu = Customer unit

Subject to alterations

Technical features

Mass

1.6 kg

Size

210 mm

Surface of rotor

Coated in black

Material of blades

Sheet steel, coated in black

Number of blades

5

Direction of air flow

"V"

Direction of rotation

Counter-clockwise, seen on rotor

Type of protection

IP 44; Depending on installation and position as per EN 60034-5

Insulation class

"F"

Humidity class

F2-2

Max. permissible ambient motor temp. (transp./ storage)

+ 80 °C

Min. permissible ambient motor temp. (transp./storage)

- 40 °C

Mounting position

Shaft horizontal or rotor on bottom; rotor on top on request

Condensate discharge holes

Rotor-side

Operation mode

S1

Motor bearing

Ball bearing

Touch current acc. IEC 60990 (measuring network Fig. 4, TN system)

< 0.75 mA

Cable exit

Lateral

Protection class

I (if protective earth is connected by customer)

Product conforming to standard

EN 60335-1

Approval

CSA C22.2 Nr.100; UL 1004-1
