Cheapest TM-600 VDSL VDSL2 Tester ADSL WAN & LAN Tester xDSL Line Test Equipment with DMM + TDR function

Description:

TM-600 VDSL tester specially designed for xDSL line test (xDSL include: ADSL, ADSL2, ADSL2+, READSL, VDSL2 etc) and maintenance It provides xDSL test, PPPoE dial test, DMM test, Modem emulation, line voltage indication and so on. TM-600 VDSL Tester also introduces the Optical Power Meter and Visual Fault Locator function into the unit, as well as the TDR function; It is one multifunction tester with smart size, true color LCD and powerful management software as well as the 6600mah rechargeable battery etc   Features: Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2 Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance) Supports Modem emulation and simulating login to Internet  Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test) Supports all multi-protocol, PPPoE Connects to CO via alligator clip or RJ11  Rechargeable Li-ion Battery  Beep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)  Data memory fuction LCD display, Menu operation  Auto shut off if no any operation on keyboard  Compliant with all known DSLAMs  Software management Simple, portable and money-saved    Main Functions: DSL Physical layer test  Modem Emulation (Replace the user Modem completely) PPPoE Dialing (RFC1683,RFC2684,RFC2516) Telephone Function DMM Test (Have) Ping Function (WAN & LAN) Data upload to computer and software management Setup system parameter: backlight time, shut off automatically time without operation, press tone,  Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.       Check dangerous voltage Optical Power Meter (Optional) Visual Fault Locator (Optional) Tone Tracker (Optional) TDR Cable Fault Locator (Have)   Specifications:

ADSL2+
Standards	ITU G.992.1(G.dmt), ITU G.992.2(G.lite), ITU G.994.1(G.hs), ANSI T1.413 issue #2, ITU G.992.5(ADSL2+)Annex L,
Up channel rate	0~1.2Mbps
Down channel rate	0~24Mbps
Up/Down attenuation	0~63.5dB
Up/Down noise margin	0~32dB
Output power	Available
Error test	CRC, FEC, HEC, NCD, LOS
Display DSL connect mode	Available
Display channel bit map	Available
ADSL
Standards	ITU G.992.1 (G.dmt) ITU G.992.2(G.lite) ITU G.994.1(G.hs) ANSI T1.413 Issue # 2
Up channel rate	0~1Mbps
Down channel rate	0~8Mbps
Up/Down attenuation	0~63.5dB
Up/Down noise margin	0~32dB
Output power	Available
Error test	LCD, OCD, HEC, FEC, CRC
Display DSL connect mode	Available
Display channel bit map	Available
VDSL2
Be compatible with ADSL2+, ADSL standard.
DSL line attenuation
DSL line noise margin
DSL line up/down channel speed (Inter/Fast mode)
DSL line up/down maximum rate
DMT sub channel bit number: 0~15, and each sub channel frequency points
DSL line error number (CRC, HEC, FEC, LCD, OCD)
DSL line local output power
DSLAM information
Error Code Second
Impulse Noise Protection (INP)
Support 7 VDSL2 profiles: profile 8a, 8b, 8c, 8d, 12a, 12b, 17a
DMM Test
DC voltage (V):	0~400
AC voltage (V):	0~400
Loop resistance(Ω):	0~20000
Capacitance (nF):	0~1000
Insulation resistance (MΩ):	0~50
General Specification
Power Supply	Internal Rechargeable 7200mAH Li-ion battery
Battery Duration	4 to 5 hours
Working temperature	10-40°C
Working moisture	5%-90%
Dimensions	170mm×70mm×52mm
Weight:	<0.6kg

  Optical Power Meter (Optional) Measurement range: -70~+10dBm or -50~+26dBm Wavelength 850nm 1300nm 1310nm 1490nm 1550nm 1625nm   Visual Fault Locator (Optional) Output Power 10mw Wavelength 650nm ± 20nm    Tone Tracker (Optional) Output Power 10mw Wavelength 650nm ± 20nm    TDR Function (Have)-Auto Test the cable fault distance (Cable Break/ Cable Mix) Test Range <2.5km Dead Zone <1m Resolution Rate 1m   Please Note: It's ADSL,VDSL with DMM + TDR Function , if you need optional function ,please contact us,optional function needs to add price
