        10.1" touch screen replacement 4 wire resistive kiosk touch screen industrial touch panel

           The 4 Wire Resitive touchscreen consists of a glass layer with a conductive coating on top and a polyester top sheet with a conductive coating on the bottom. The conductive surfaces are held apart by "spacer dots", usually glass beads that are silk-screened onto the coated glass.

        When a person presses on the top sheet, its conductive side comes in contact with the conductive side of the glass, effectively closing a circuit (this is called pressure sensing). The voltage at the point of contact is read from a wire connected to the top sheet.It can be touched by finger, gloved finger, leather or stylus pen.It is inherently of many advantages such as high accuracy, quick response, drift-free, stable and long durability for a life time of 1,000,000 times finger touches.

> Can withstand more than 1,000,000 point
> 4096x4096 Resolution
> USB or RS232 Interface
> High accuracy and sensitivity
> Glass + Film or Film + Film Material
> Finger, gloved hand and touch pen activation
> Operable in various light conditions, indoor and outdoor
> Our products have passed CE, FCC, ROHS certification!
