Product Description

• Wide input voltage from 30V-58V(for example: 36V48V battery or 30V-58V switching power supply);

• Stable output voltage is 13.8V;

• Work for appliances from 1AMP to 25AMP automatically;

• 100% full rated power;

• 100% full stable output current;

• 100% burn-in test;

• High-efficiency up to 96%;

• Waterproof sealed;

• Cooling by free air convection;

• Surface mountable;

• 1-3 year warranty;

• Over-current, over-voltage protections;

• Over-temperature protection;

• According to: EN 50498:2010 IP68;

Product Size (L x W x H) andProduct Weight(the product Can be used within the current value range):

2A(ZS):46*32*18(Length*Width*Height) mm 55 grams/pcs;(0.5-2ACan be used)

3A(JL):45*24*20(Length*Width*Height) mm 45 grams/pcs;(0.5A-3A Can be used)

6A(DS):58*40*22(Length*Width*Height) mm  97 grams/pcs;(1A-6A Can be used)

8A(ZL):65*58*22(Length*Width*Height) mm 120 grams/pcs;(1A-8A Can be used)

10A(DL):75*75*32(Length*Width*Height) mm260grams/pcs;(1A-10ACan be used)

15A(DL):75*75*32(Length*Width*Height) mm  260grams/pcs;(1A-15ACan be used)

20A(DL):75*75*32(Length*Width*Height) mm  260 grams/pcs;(1A-20ACan be used)

25A(DL):75*75*32(Length*Width*Height) mm  260 grams/pcs;(1A-25ACan be used)

Notes:

Please connect the polarity correctly,or the converter will be burnt.

This DC/DC Converter can't work as solar controlleror wind controller.
