Новый 12В 24В 50мм 2-дюймовый регулируемый ход 1200Н 120кг груза 160мм/с скорость производителя промышленных линейных приводов LA10DW.

Новый 12В 24В 50мм 2-дюймовый регулируемый ход 1200Н 120кг груза 160мм/с скорость производителя промышленных линейных приводов LA10DW.

Spec

 1    Type                         LA10DW

 2    Input                        12V 24V DC

 3    Max Load                  1200N=120KG=264LBS

 4    Speed Options           Max 150mm/s

 5    Limited  switch           With

 6    Duty cycle                  25%

 7    House material            Metal

 8    Inner tube material      Aluminum Alloy

 9    Stroke length               50mm=2inch

10   Color                             Silver

11    Operation temperature   -26 ~ +65 degree

Drawing:

1.  Retracted length=Lmin=105+Stroke=105+50=155mm

Lmin means the length when linear actuator 100% fully retracts, meanwhile,it will touch the tail limited switch and stop automatically,very safe.

2.  Stroke means the movement length of linear actuator.

3.  Lmax=Lmin+Stroke=155+100=255mm

Lmax means the length when linear actuator 100% fully extends, meanwhile,it will touch the head limited switch and stop automatically,very safe.

Questions

1 Can you supply customized installation hole and Lmin size? Yes

2 Can you supply black color? Yes

3 For limited switch Is it adjustable?  Sorry,it is not.

4 Can you provide control unit or adapter or hand switch or remote?  Yes.

5 Can you provide special cable connector?  Yes.

6 Do you have bracket and rubber protector? Yes

7 For head connector,I want U type and drill customized hole. Yes

8 Can you add hall sensor,encoder or potentiometer? Yes.

8 We supply free spare parts for after-sales-service as we are manufacturer.

Similar product link

Other product link

What can we do

1 Why your load capacity is stronger than others?

My answer: I use high effecient and smart motor,with Europe spare parts.

2 Why your linear actuator is heavier than others?

My answer: I use solid steel materials.

3 More than 15 years experience engineer team,2 factory,25 engineers.

4 We are manufactuer,not trader or wholesaler or retailer,we focus on linear actuator,and offer free spare part even warranty time is end.

Warranty

1. If you do not receive product, we will full refund you.

2. If the product has quality problem, we will full refund you.

3. If the product is damaged by express company, we will full refund you.

Payment

1. We accept paypal, Escrow,Western union and bank transfer.

Shipping

1. Order will be delivered soon after confirmation.

2. Please make sure your address and phone is correct.

Thanks for visiting my store. Any help,please contact with engineer sales.

Please do not leave negative feedback,as it may be not our problem. For any question,please contact with us and we will try our best to solve it.
