The color will be sent randomly. Package includes: 1 piece of motion sensor switch   The product will be upgraded constantly, the appearance and color may be changed, please don't mind. And take a consideration before place the order if you have request for color or appearance.     Product parameters Detection range: 180° Detection distance: 2-12 meters (22~24 °C) Delay time: 5 seconds ~ 10 ± 2 minutes (adjustable) Power supply voltage: 110~130V/AC, 220~240V/AC Power frequency: 50/60Hz Rated load: 800W (110~130V/AC), 1200W (220~240V/AC) Working humidity: <93% RH Ambient illumination: <10Lux~2000 Lux (adjustable) Operating temperature: –10°C~ +40°C Installation height: 2 m ~ 4.5m       Infrared human body sensor switch manual (Model: JXJ-P06)    First, the product overview:   This product uses infrared human body sensing and light control technology. Control the load by detecting the movement of the human body (more practical, stable, energy-saving and user-friendly than the traditional touch, voice-activated switch). The person lights up to the sensing area, and when the person leaves, it automatically turns off according to the set time. It can recognize day and night (that is, you can manually adjust the knob to select day and night work), product performance is stable, safe and convenient, and energy saving. It is the first choice for intelligent lighting and security.   Second, the applicable places:   Doorways, corridors, corridors, elevators, balconies, bathrooms, mirrors, wardrobes, cabinets, warehouses, basements, garages, etc.   Third, the use of instructions:   1. Install this switch to a qualified electrician for installation. 2. Turn off the main power supply before installation (no live operation), install the switch as required, connect the wiring according to the diagram and fix the switch, then turn on the main power.   Fourth, note:   1. Please strictly follow the wiring diagram. 2. Do not use overload or over-range. 3. This product can be applied to resistive and inductive loads such as incandescent lamps, fluorescent lamps, LED lamps, etc. and automatic switch control of electrical equipment.   Fifth, technical parameters:   1, working voltage: AC 220 ~ 240V. Power consumption: 0.1W. 2, the ambient temperature: -20 ° C ~ +40 ° C 3, delay time: 5 seconds to 10 minutes can be adjusted with the TIME knob 4, the maximum load power: 1200W (resistive load such as incandescent lamps, etc.), 300W (inductive load such as fluorescent lights, LED lights, etc.) 5, sensing distance: 12 ± 2 meters 6, sensing angle: 180 ° 7, sensing ambient light: 3 LUX (evening) to 2000LUX can be adjusted with LUX knob. When LUX is adjusted to the sun position, it is sensed during the day and night; when it is adjusted to the moon position, it is only detected at night. 8. Installation height: 1.8 to 4.5 meters 9. Protection level: IP44 (suitable for outdoor and indoor use) 10. The maximum sensing distance is 12 meters, which refers to the maximum detection distance of the infrared sensing element. In actual use, it may be affected by factors such as ambient temperature, installation method, position of the detected object, hot and cold airflow, etc. The actual detection distance is less than 12 Meter.   Installation Precautions:   1. Ask an electrician or a person with relevant experience to install it; 2. Do not use turbulent objects as the mounting base; 3. There should be no obstacles in front of the detection window that affect its detection, and objects that keep moving; 4. Do not install in areas where the airflow has obvious changes; such as: air conditioners, heaters, etc.; 5. If the sensor is found to be faulty after installation, please do not open the sensor housing for your safety.
