Характеристики
Сопло горелки отработанного масла распылитель воздуха сопло мазута распылителя
История изменения цены
*Текущая стоимость 2 380,80 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Sep-18-2025 | 2832.83 руб. | 2974.55 руб. | 2903 руб. |
| Aug-18-2025 | 2808.76 руб. | 2948.18 руб. | 2878 руб. |
| Jul-18-2025 | 2356.47 руб. | 2474.20 руб. | 2415 руб. |
| Jun-18-2025 | 2761.30 руб. | 2899.71 руб. | 2830 руб. |
| May-18-2025 | 2404.93 руб. | 2524.90 руб. | 2464 руб. |
| Apr-18-2025 | 2713.79 руб. | 2849.38 руб. | 2781 руб. |
| Mar-18-2025 | 2689.67 руб. | 2823.53 руб. | 2756 руб. |
| Feb-18-2025 | 2666.13 руб. | 2799.49 руб. | 2732.5 руб. |
| Jan-18-2025 | 2642.51 руб. | 2774.40 руб. | 2708 руб. |
Описание товара
Whats app: +86-15917492987
Wechat/LINE Number:+86-15917492987
Skype:+86-15917492987
Email: nicolaspray@163.com
Product Details:
Total length: 78mm
Nozzle Material: Stainless Steel
Air inlet：1/4", please insert a hose with Φ8mm or 6mm Gas/Oil inlet: 1/8", please insert a hose with Φ8mm or 6mm Bore diameter: 0.5mm 0.8mm 1.0mm 1.5mm 2.0mm 2.5mm 3.0mm 3.5mm 4.0mm Product Overview: Brass Siphon Air Atomizing Fuel Oil Burner Nozzle is a low pressure can spray atomization of the best at low pressure air atomizing nozzle. Widely used in diesel, heavy oil, waste oil, animal and vegetable oils, alcohol-based fuel burner system, and for kerosene, oil atomization. Product Characteristics: · The use of compressed air to swirl inside the tubes and mix the atomized droplets impact. · Can produce tiny micro particle size mist particles at low pressure and low volume conditions. · Can control the air flow and pressure to adjust the spray flow, angle and size granularity. · Since the fluid passage of nozzle is large, it have a good anti-clogging effect. · In the heavy oil, waste oil burner, oil and other application viscosity of the liquid atomization effect is very good. · The working pressure range is 0-10/kg/cm2, different flow capacity needs different filter screen Flow capacity range is 1.5-1.7 L/h, needs a 45um oil filter screen Flow capacity range is 1.89-3.78 L/h, needs a 75um oil filter screen Flow capacity range is 4.76-5.10 L/h, needs a 125um oil filter screen Flow capacity range is 5.68-41.64 L/h, needs a 140um oil filter screen Flow capacity over 45.42L/h, no need for oil filter screenWorking pressure is 3 bar:
0.5mm diameter, the liquid water flow is 4 L/H;
0.8mm diameter, the liquid water flow is 6 L/H;
1.0mm diameter, the liquid water flow is 8 L/H;
1.5mm diameter, the liquid water flow is 11L/H;
2.0mm diameter, the liquid water flow is 14L/H;
2.5mm diameter, the liquid water flow is 17L/H;
3.0mm diameter, the liquid water flow is 20L/H;
3.5mm diameter, the liquid water flow is 23L/H;
4.0mm diameter, the liquid water flow is 26L/H;
The siphon height is 30cm, and the spray angle is 15-45 degree.
Kindly be noted above data is base on water for reference
Test: Normally the working pressure is 3 bar, for 1.00mm version, the liquid waste is 10L/H. For 2.0mm version, the liquid waste is 19L/H. For 3.0mm version, the liquid waste is 28L/H. The capacity tolerance is ±10%. The siphon height is 30cm, and the spray angle is 45 degree. Kindly be noted above data is base on water for reference, if you use other liquid, you can calculate it by the proportion of density. Installation: The air compressor should be capable of providing at least 10% more air than the specified values. All fuel and airline connections must be tight. Any leaks, especially in the fuel line, will have an adverse effect on the lift characteristics. The nozzle will flow in either a horizontal or vertical position. The lift distance for a vertical mounted nozzle is measured from the liquid level to the end (face) of the nozzle. The lift distance for the horizontal mounting is shown in the installation drawing. If the combustion application does not permit the use of a constant level device, excellent spray characteristics can be obtained using a fuel metering pump and an air compressor. It is also possible to operate the nozzle in a closed pressurized system utilizing air pressure for both lifting and atomizing the fuel. Feedback: -All products are 100% original new and tested again before shipment.Customers' satisfactory is our goal. -Any feedback from you will be much appreciated. If you're satisfied with our service or products, please give us 5 stars. -If you have any questions, please contact with us, and we will get back to you sooner.
