DC12V 24V 15CH RF Wireless Remote Control Switch transmitter & receiver Light /curtain /door control power on off | Обустройство

DC12V 24V 15CH RF Wireless Remote Control Switch transmitter & receiver Light /curtain /door control power on off | Обустройство

  Receiver  Working Voltage :  DC 12V  24V Quiescent Current : less than 8mA Working Temperature: -20'C- +70'C Receiving sensitivity: more than -105dBm Working Frequency: 315MHZ Output Type: Input DC12V Output 0V Switching Value use Relay NO COM NC Relay: 10A Relay have better load less than 5A Size:125mm*80mm*30mm Working Mode: 1--------15CH Toggle  use " 1 " Button to Learn  2--------15CH Momentary use " 2" Button to Learn 3--------15CH Latched use "3" Button to Learn     Learning Code: Input DC12V for the Receiver, Press the Learning Button on the Receiver ,LED Indicator ON ,Release it, then press the relative Transmitter Button, Receiver LED Indicator flash for 1 time, it mean learning is successful.   Clearing Code: Input DC12V for the Receiver, press the learning button on the receiver and hold for about 8s until the Receiver LED indicator OFF, it mean the code have been cleared.   the Receiver can keep 30 pcs different code transmitter     Transmitter Working voltage: DC12V 23A Battery Working Current: less than 25mA Working Frequency:315MHZ

package included:
1*receiver
1* transmitter
