FREE SHIPPING(Some countries free shipping)

Updated 1.5KW WATER-COOLING SPINDLE MOTOR and MATCHING INVERTER

FOR NUMERICAL ENGRAVING/GRINDING/MILLING

 Package Contents:

1pcs 1.5Kw Spindle motor

1pcs 1.5Kw inverter

13pcs ER11 chuck(1-7mm)

New Upgraded With
Adopt Germany Imported Bearing: three times useful time than ordinary spindle motor
MORE PRECISE
MORE SPEED: 0-24000 R/min
Collet: ER11(3.175mm,4mm,6mm)   Runout off: less than 0.005mm
PASS ISO9001 quality certification which means this item is the top quality item
Brand new sealed in factory CARTON

2 YEARS WARRANTY

Ship from USA,DUTY FREE

DHL OR FedEx SERVICE with TRACKING NUMBER
Manufacture Suggested Retail Price:1699USD

Technical Parameters
Technical Parameters for Spindle Motor

1) Diameter: 80mm x Length:188mm (including air interface: 80mm X 203mm)

2) Power: 1.5 KW

3) Voltage:220v
4) Frequency: 400 Hz

5) Speed: 0-24000 R/min

6) Water Cooling

7) ER11(3.175mm,4mm,6mm) collet chuck

8) Runout off: less than 0.005mm

9) Grease Lubrication


Technical Parameters for Variable Frequency Drive Inverter

1) Inpute Voltage: 220±15%

2) Output Voltage ? 208-240VAC (analogous to Input Voltage)

3) Inpute Frequency: 48-63 Hz

4) Outpute Frequency: 0-400 Hz

5) Inpute Phase: suit for 1 phase input, and also suit for 3 phase input

6) Outpute Phase: 3 phase

7) Item Manufactuer: From a well-known manufacture who manufacture VFD for more than 12 years.

8) Warranty: 2 years

• This spindle motor adopts Germany imported bearing which can make it use for three times longer useful time than ordinary spindle motor. In extremely high speed working environment, ordinary bearing can not ensure this high rotate speed for using for long time. Our Germany imported bearing can make spindle motor three times longer useful time than ordinary spindle motor. The cost for Germany Imported Bearing is more than 150$ than ordinary bearing.

• MORE SPEED: 8000-24000 R/min
• MORE PRECISE
• It can work 24 hours one day in very bad environment.
• Collet: ER11(3.175mm,4mm,6mm)   Runout off: less than 0.005mm
• ISO9001 quality certifications which means this item is the top quanlity item

Item Units and Pictures(what you see what you get)

Product Certificate(ISO9001 Certificate)

FOR ALL OF OUR CLIENTS

NOTICE: There are many new brand name of similar item in the market recently, although their price are really cheap, but the quality of their products are also terrible:

1. That factory only produce as a lower price as they can, they won't care about the quality.All our item is pass the ISO9001 quality certification

2. Have visit and purchase the item samples from some other supplier, many samples are in bad quality. After compare samples again and again from different supplier, finally we provide this top-quality item for you at lowest price.

3. You can purchase a high quality and safety machine, but please don't waste the money for a cheaper but a low quality machines. We only sell top-quality item. Base on the top-quality, then we will beat our price as lowest on AliExpress

4. We keep a good relationship with the supplier, so that we can get the stable and reliable stock for our client.

5. We only sale the top-quality machine, we can provide the reasonable price since we have fight with the supplier as a lowest cost as we can.
