Fiber Count

Cable Dimension
mm

Cable Weight
kg/km

Tensile
N

Crush
N/100mm

Min. Bend Radius
mm

Temperature

Long Term

Short Term

Long Term

Short Term

Dynamic

Static

2 or 4

7.0

42.3

200

400

1100

2200

20D

10D

-40 ~ 85°C

Note: 1. All the values in the table, which are for reference only, are subject to change without notice;
2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter;
3. D is outer diameter of the round cable;

CableModel

GYFJH-4B1 /GYFJH-2B1 / GYFJH-2A1,

Fiber Count

2, 4 Fibers

Fiber Type

SM G652D, SM G657A, or MM 50/125 or MM 62.5/125

Buffer Diameter

900um±10um Material LSZH

Simplex cable Diameter

2.0mm±0.1mm Material LSZH

Color

Orange or grey or customized

Filler Diameter

2.0mm±0.1mm

Material LSZH

Color Black

Strength Member

Kevlar

Jacket Diameter

7.0±0.1mm

material PE

Color Black
